Experiment of The Month

Calculus in Physics

Error Propagation

The experience which may bring calculus most directly to physical events is the propagation of experimental error. We follow the development shown at http://mathworld.wolfram.com/ErrorPropagation.html

Suppose that we take measurements of parameters x and y, and need to use them to calculate a function f(x,y). We ask how a variation in x or y will change the value of f. To approach the topic gently, we imagine differentiating with respect to a dummy variable, z. (z might represent the trial number if we repeat the measurement a number of times.):

Students know the chain rule, although most are not familiar with the partial derivative notation. We next use "physics license" to "multiply through by dz," making apologies and mentioning first order Taylor series expansion:

Next we argue that if the variation in x, dx, is due to error in x, we can estimate the error in f that is generated by this error in x, using the differential expression:

A similar expression is true for the error due to the error in y. This is a natural point to notice that we can use this differential method to determine which measurement deserves the most attention if we want to reduce the error in f - it is the measurement which contributes the greatest error.

The fact that the derivative can be either positive or negative requires attention. If there were only one parameter, x, then we could just take the absolute value of the derivative. Since the x value can vary + or - the error in x from the best value, the sign of the derivative does not matter.

If there are several parameters, we must find a rule for combining the errors, in the face of the likelihood that some derivatives are negative and some are positive. Simply adding can lead to non-representative conclusions, such as an error in f that is zero.

The simpler way to deal with the negatives is less supportable. We call it the "worst case" estimate of error. For the worst case, we simply add the magnitudes of each error contribution. The statistically valid method is to calculate the square root of the sum of the squares of all error contributions.

The error discussion was extended because it gives students a reason to use calculus in the laboratory, calculating the derivatives for themselves. Comparing measurement errors with function errors makes concrete a basic concept in calculus; the connection between change in an independent variable such as x, and change in the dependent variable, f. The calculus prerequisite also allows better exposition in lecture, as briefly described below:

Motion with constant acceleration

With velocity defined as the derivative of position and acceleration as the derivative of velocity, we can immediately ask for the consequences of the special case when acceleration is constant. Integrating the expression with an indefinite integral exposes the physical significance of constants of integration:

Integration of the constant acceleration, and identification of the constant of integration with (-) the initial velocity gives the usual formula, v=at+v₀.

Similar reasoning gets the equation for position as a function of time, with a second constant of integration connected to the initial position.

The work-energy theorem

The work-energy theorem arises naturally from considering the definite integral

The right hand integral can be done to give the difference in kinetic energy. Potential energy arises from consideration of the individual contributions to the force integral. Those which are path independent lead to potential energy differences.

Center of mass

If we define momentum of a system as the vector sum of the momenta of its parts, and the mass of the system as the sum of the masses of its parts, the center of mass arises by requiring that the velocity of the system be equal to two things:

and

The usual result is obtained by setting the constant of integration equal to zero.
